GDT Razer Demolition Tool

GDT Razer Demolition Tool

Yellow Genesis Razer Demolition Tool with open jaws facing left.
Yellow Genesis Razer Demolition Tool with open jaws facing right.
Summary

GDT Razer Demolition Tool

The GDT Razer Demolition Tool is designed for today’s new classes of excavators and specialty, high-reach applications.



  • Crushing teeth are available in several configurations to maximize performance in any application
  • Reversible, long-life crushing teeth are quickly and easily replaced, eliminating build-up
  • 4-way indexable cutting blades feature an apex that draws material deeper into the jaw for more efficient cutting
  • Short, flat-top head with bolt-on bracket shortens the center of gravity making it easy to change mounting for different carriers
The GDT Razer Demolition Tool, now available in five sizes, is designed for high-reach demolition.
The GDT Razer Demolition Tool, now available in five sizes, is designed for high-reach demolition.
  • Specifications
  • Description
  • Literature
  • Manuals
  • Conversion Block
ModelWeight* (lbs.)Jaw Opening (ins.)Jaw Depth (ins.)Reach** (ft. ins.)Min. Excavator Weight
Stick Mount (lbs.)
GDT 1904,90031338' 0"45,000
GDT 2907,00039429' 2"66,000
GDT 39010,000464510' 6"90,000
GDT 59015,1005246.512' 4"120,000
GDT 89020,000646213' 10"180,000

*Weight includes mounting bracket to attach to excavator.
**Distance is measured from the attachment mounting pivot (boom or stick) forward.
All Genesis GDT Razer tools are covered by a 12-month, 1,500-hour (whichever occurs first) warranty.

The GDT Razer Demolition Tool is designed for today’s new classes of excavators and specialty, high-reach applications.


Featuring a lighter-weight design, this demolition attachment is optimized to fit on standard and most high-reach excavators. A short, flat-top head with bolt-on bracket makes installation simple, shortens the center of gravity and makes it easier to switch the GDT between excavators.



The number of crushing teeth and their locations can be customized to meet project needs, and the bolt-on teeth can be interchanged and reversed front to back for longer life and lower cost of operation and ownership.


The GDT is a concrete processor and demolition shear designed for applications including high-reach demolition, general and bridge demolition, concrete recycling, C & D processing, and structural steel, rebar, wire and aluminum processing.



For additional product, application or service information, call us at 1-888-SHEAR-IT.
