GSG Scrap Grapple

GSG Scrap Grapple

Yellow Genesis Scrap Grapple with open tines.
Summary

GSG Scrap Grapple

The Genesis Scrap Grapple is a low-maintenance, high-capacity orange peel grapple designed for high volume scrap processing.



  • Heavy-duty guarding protects cylinders and internal components
  • Reverse-mounted cylinders protect rods from damage
  • Tines feature fully-boxed construction for strength and durability
  • Overall footprint easily fits inside trailers
The Genesis Scrap Grapple provides high-capacity processing with less maintenance.
The Genesis Scrap Grapple provides high-capacity processing with less maintenance.
  • Specifications
  • Description
  • Literature
  • Manuals
  • Conversion Block
ModelCapacity (yd3)Weight** (lbs.)Min. Machine Size (mt)
Jaw Open Width (ins.)
Tine Shape
FlatPoint
Jaw Open Height (ins.)
Tine Shape
FlatPoint
Jaw Closed Width (ins.)
Tine Shape
FlatPoint
Jaw Closed Height (ins.)
Tine Shape
FlatPoint
Footprint
(ins.)
Tine Shape
FlatPoint
GSG 500.53,05020
***64
***81
***52
***88
***60
GSG 650.653,15020
***69
***83
***54
***91
***64
GSG 750.753,25020
7476
***85
***59
9195
***70
GSG 10013,50022
7980
***90
***68
93100
***73
GSG 100 HD*14,30025
7879
7786
6663
9198
7172
GSG 1251.253,60022
8986
***92
***71
98101
***79
GSG 125 HD*1.254,50027
8586
7988
7167
95102
7778
GSG 1501.54,80030
9189
8194
7572
100108
8081
GSG 20025,00040
9695
8296
7876
103112
8486
GSG 2502.55,70045
108105
84100
8685
109118
9495

*Heavy-duty
**Weight includes yoke
***Contact your local Genesis Regional Manager for additional information.
Genesis Scrap Grapples are covered by a 12-month, 1,500-hour (whichever occurs first) warranty.

The Genesis Scrap Grapple is a low-maintenance, high-capacity orange peel grapple designed for high volume scrap processing.



Available in 10 models, the GSG features large-bore hydraulic cylinders that maximize clamping force and high-torque, continuous 360-degree rotation for handling large and uneven loads. Large diameter hardened steel pins with integrated shear-proof pin retainers and identical hardened steel bearings with dust seals at all pivot points minimize maintenance.



The Genesis Scrap Grapple is also suited for C&D sorting, bulk material handling and other applications in which volume and uptime are key.



For additional product, application or service information, contact us at 1-888-SHEAR-IT.
