Summary

GXT Mobile Shear

The Genesis XT Mobile Shear is designed to process steel and other materials more efficiently in scrap and demolition applications and fit on smaller carriers.



  • All the power in a shorter, lighter shear
  • Bolt-on piercing tip encapsulates front of upper jaw, minimizing risk of damage while reducing welding build-up and downtime
  • Short primary cutting blades position the apex closer to the rear of the jaws and draw material further into the jaws where higher force makes efficient cuts
  • Lower shear height improves visibility
GXT Mobile Shear - Large Shear Power, Shorter & Lighter Design
GXT Mobile Shear - Large Shear Power, Shorter & Lighter Design
  • Specifications
  • Description
  • Literature
  • Manuals
  • Conversion Block
ModelWeight* (lbs.)Jaw Opening (ins.)Jaw Depth (ins.)Reach** (ft. ins.)Min. Excavator Weight
Boom Mount*** (lbs.)
Min. Excavator Weight
Stick Mount*** (lbs.)
GXT 115****3,10016185' 0"15,00025,000
GXT 115R****3,55016187' 8"18,00030,000
GXT 2254,20018205' 8"25,00035,000
GXT 225R4,90018207' 11"30,00045,000
GXT 3356,50023266' 5"27,00045,000
GXT 335R7,30023268' 11"37,00066,000
GXT 4459,50028287' 2"40,00075,000
GXT 445R11,000282810' 1"48,00090,000
GXT 55511,60030308' 0"50,00090,000
GXT 555R13,100303011' 0"55,000110,000
GXT 66513,20032329' 0"55,000110,000
GXT 665R14,700323212' 0"68,000120,000
GXT 77515,50035379' 8"68,000135,000
GXT 775R17,750353713' 0"79,000150,000
GXT 99518,000394210' 8"79,000170,000
GXT 995R20,000394214' 2"100,000180,000
GXT 155523,000444613' 5"110,000190,000
GXT 1555R26,750444617' 2"145,000250,000
GXT 205532,000485014' 5"145,000Contact Factory
GXT 2055R36,200485017' 7"180,000Contact Factory
GXT 255550,500545615' 5"Contact FactoryContact Factory
GXT 2555R56,500545621' 5"Contact FactoryContact Factory

*Weight includes mounting bracket to attach to excavator.
**Distance is measured from the attachment mounting pivot (boom or stick) forward.
***2nd-member installations that are at or near minimum excavator weight and all 3rd-member installations require pre-approval from Genesis.
****The GXT 115 and GXT 115R have a single guide blade.
GXT shears are covered by a 12-month, 1,500-hour (whichever occurs first) warranty.

The Genesis XT Mobile Shear is designed to process steel and other materials more efficiently in scrap and demolition applications and fit on smaller carriers, reducing initial acquisition investments and hourly energy consumption costs.



The GXT is a lighter-weight mobile scrap shear that features a center of gravity closer to the excavator, enabling models to mount on excavators that could previously only carry smaller, less powerful shears.


This scrap and demolition shear features:

  • Improved jaw geometry that makes it easier to pick up material and reduces ground contact wear
  • A reverse-mounted hydraulic cylinder that shortens shear length and reduces weight
  • A weld-on, replaceable, highly abrasion-resistant steel rhino horn that protects the front of the upper jaw, reducing welding build-up



For additional product, application or service information, call us at 1-888-SHEAR-IT.
